Stainless steel butterfly valve wafer type

Body, stem and disc: stainless steel 316 (CF8M).
Stainless steel butterfly valve wafer type.
Seat: PTFE with EPDM backup ring. Temp. -25ºC +180ºC.
Manually operated by stainless steel handle until 5”, from 5” with gear operator. Face to face according to DIN 3202 K1. Working pressure: 10 bar
With GNP actuator.
-13ºF + 356ºF

Reference: 5114

Valve Technical Sheet
GNP Actuator technical sheet
GNP Actuators folder
Consult product
Reference Size Minimum purchase unit Weight (Kg) Box / carton
5114 09 63 V. 2104 2" WITH GN-15 1 0.01 1/1
5114 10 52 V. 2104 2"1/2 WITH GN-17 1 0.01 1/1
5114 11 64 V. 2104 3" WITH GN-20 1 7.77 1/1
5114 12 65 V. 2104 4" WITH GN-25 1 10.5 1/1
5114 13 67 V. 2104 5" WITH GN-35 1 15.78 1/1
5114 14 68 V. 2104 6" WITH GN-40 1 18.63 1/1
5114 16 97 V. 2104 8" WITH GN-50 1 32.5 1/1
5114 18 84 DOUBLE ACTING ACTUATOR: GN OR GNP 1 47.1 1/1
