2 pieces full bore ball valve / Gen-Air Actuator

2 pieces full bore ball valve. Body: Stainless steel. CF8M (316) investment casting.
Seats: PTFE + 15% GF stem o’ring: viton. Antiestatic device.
Max. pressure: 40/16 BAR depending on size.
Temp.: -30ºC +180ºC. manually operated by handle.
L: DIN 3202 F-4 DN 15 DN 100 F-5 DN 125 DN 200.
With Gen-Air Actuator

Reference: 5528

Gen-Air Actuator technical sheet
Valve Technical Sheet
Consult product
Reference Size Minimum purchase unit Weight (Kg) Box / carton
5528 04 44 V. 2528 1/2" WITH GN-05 1 3.05 1/1
5528 05 44 V. 2528 3/4" WITH GN-05 1 3.9 1/1
5528 06 44 V. 2528 1" WITH GN-05 1 4.6 1/1
5528 07 63 V. 2528 1"1/4 WITH GN-15 1 7.58 1/1
5528 08 63 V. 2528 1"1/2 WITH GN-15 1 8.83 1/1
5528 09 52 V. 2528 2" WITH GN-17 1 11.85 1/1
5528 10 64 V. 2528 2"1/2 WITH GN-20 1 17.62 1/1
5528 11 65 V. 2528 3" WITH GN-25 1 22.85 1/1
5528 12 67 V. 2528 4" WITH GN-35 1 33.11 1/1
5528 16 84 V. 2528 8" WITH GN-55 1 132.98 1/1
