Sanitary ball valve end threaded/welded

Construction: stainless steel AISI 304. Threaded
DIN 11851/welded end. Seats: PTFE, gasket: NBR.
Maximum working pressure: 10 bar. Maximum temperature:120ºC.
Manually operated: 2 position.

Reference: 2932

Valve Technical Sheet
Installation Manual
Consult product
Reference Size Minimum purchase unit Weight (Kg) Box / carton
2932 06 SANITARY B.V. END THREADED/WELDED 1" 1 1.76 1/10
2932 08 SANITARY B.V. END THREADED/WELDED 1"1/2 1 2.576 1/8
2932 09 SANITARY B.V. END THREADED/WELDED 2" 1 3.5 1/4
2932 10 SANITARY B.V. END THREADED/WELDED 2"1/2 1 6.932 1/3
2932 11 SANITARY B.V. END THREADED/WELDED 3" 1 9.29 1/2
