Pressure gauge Ø 53, bottom outlet, BSP thread 1/4".

ABS box. Brass bourdon tube and fitting UNE-EN 12165. 1/4" male gas thread (BSP). Graduations available 0 to 2,5-4-6-10-16-25 bar. Bottom outlet (radial). Accuracy class 2,5.

Reference: 3820

See Technical Sheet
Consult product
Reference Size Minimum purchase unit Weight (Kg) Box / carton
3820 002 PRESSURE GAUGE Ø 0 TO 2,5 1/4" 1 0.063 20/180
3820 004 PRESSURE GAUGE Ø 0 TO 4 1/4" 1 0.062 20/180
3820 006 PRESSURE GAUGE Ø 0 TO 6 1/4" 1 0.063 20/180
3820 010 PRESSURE GAUGE Ø 0 TO 10 1/4" 1 0.063 20/180
3820 016 PRESSURE GAUGE Ø 0 TO 16 1/4" 1 0.064 20/180
3820 025 PRESSURE GAUGE Ø 0 TO 25 1/4" 1 0.064 20/180
3820 160 PRESSURE GAUGE Ø 53 1 0.075 20/180
