Ball valve threaded/welded end

Ball valve threaded/welded end.
Construction: stainless steel AISI 304. Threaded
DIN 11851/welded end. Seats: PTFE, gasket: NBR.
Maximum working pressure: 10 bar. Maximum temperature:120ºC.
Manually operated: 2 position.
With GNP actuator.

Reference: 5032

GNP Actuator technical sheet

Valve Technical Sheet

Consult product

Reference	Size	Minimum purchase unit	Weight (Kg)	Box / carton
5032 04 13	V.2 PZAS.ROSCA GAS 1/2" PP-0	1	3.74	1/1
5032 04 16	V.2 PZAS.ROSCA GAS 1/2" PP-0S	1	4.01	1/1
5032 05 13	V.2 PZAS.ROSCA GAS 3/4" PP-0	1	1.2	1/1
5032 05 16	V.2 PZAS.ROSCA GAS 3/4" PP-0S	1	1.47	1/1
5032 06 122	2932 1" C/ACT. GNP-14	1	3.49	1/1
5032 06 13	V.2 PZAS.ROSCA GAS 1" PP-0	1	1.39	1/1
5032 06 136	2932 1" C/ACT. GNP-44/S5	1	4.3	1/1
5032 06 16	V.2 PZAS.ROSCA GAS 1" PP-0S	1	1.66	1/1
5032 07 13	V.2 PZAS.ROSCA GAS 1 1/4" PP-0	1	1.71	1/1
5032 07 17	V.2 PZAS.ROSCA GAS 1 1/4"PP-1S	1	3.22	1/1
5032 08 128	2932 1"1/2 C/ACT. GNP-44	1	4.9	1/1
5032 08 13	V.2 PZAS.ROSCA GAS 1 1/2" PP-0	1	1.92	1/1
5032 08 144	2932 1"1/2 C/ACT. GNP-94/S5	1	6.93	1/1
5032 08 17	V.2 PZAS.ROSCA GAS 1 1/2"PP-1S	1	3.43	1/1
5032 09 128	V. 2932 2" W/ACT. GNP-44,	1	5.87	1/1
5032 09 13	V.2 PZAS.ROSCA GAS 2" PP-0	1	2.56	1/1
5032 09 148	V. 2932 2" W/ACT. GNP-135/S5	1	9.77	1/1
5032 09 17	V.2 PZAS.ROSCA GAS 2" PP-1S	1	4.07	1/1
5032 10 14	V.2 PZAS.ROSCA GAS 2 1/2" PP-1	1	4.84	1/1
5032 10 142	2932 2"1/2 C/ACT. GNP-94	1	9.94	1/1
5032 10 152	2932 2"1/2 C/ACT. GNP-198/S4	1	11.98	1/1
5032 10 17	V.2 PZAS.ROSCA GAS 2 1/2"PP-1S	1	5.58	1/1
5032 11 14	V.2 PZAS.ROSCA GAS 3" PP-1	1	6.66	1/1
5032 11 142	V. 2932 3" W/ACTUATOR GNP-94 F05/F07	1	2	1/1
5032 11 160	V. 2932 3" W/ACTUATOR GNP-300 S5	1	20	1/1
5032 11 18	V.2 PZAS.ROSCA GAS 3" PP-2S	1	10.26	1/1
