Stainless steel butterfly valve wafer type

Body, stem and disc: stainless steel 316 (CF8M).
Stainless steel butterfly valve wafer type.
Seat: PTFE with EPDM backup ring. Temp. -25ºC +180ºC.
Manually operated by stainless steel handle until 5”, from 5” with gear operator. Face to face according to DIN 3202 K1. Working pressure: 10 bar
With GNP actuator.
-13ºF + 356ºF

Reference: 5114

Valve Technical Sheet
GNP Actuator technical sheet
GNP Actuators folder
Consult product
Reference Size Minimum purchase unit Weight (Kg) Box / carton
5114 09 77 V. 2104 2" WITH GN-25/S4 1 0.01 1/1
5114 10 85 V. 2104 2"1/2 WITH GN-25/S5 1 0.01 1/1
5114 11 78 V. 2104 3" WITH GN-30/S4 1 10.47 1/1
5114 12 88 V. 2104 4" WITH GN-35/S5 1 15.52 1/1
5114 13 89 V. 2104 5" WITH GN-45/S5 1 23.22 1/1
5114 14 98 V. 2104 6" WITH GN-50/S5 1 32.23 1/1
5114 16 99 V. 2104 8" WITH GN-60/S5 1 60.6 1/1
