3 pieces ball valve / Gen-Air actuator

3 pieces ball valve. Const.: stainless steel CF8M (316) investment casting gas thread ISO 7-1 (EN 10226-1). Seats and seats: PTFE +15% GF o’ring stem: viton PN 63. Temp. -25ºC +180ºC. Direct assembling ISO 5211 with locking system.
With Gen-Air actuator

Reference: 5025

Gen-Air Actuator technical sheet
Valve Technical Sheet
GNP Actuators folder
Consult product
Reference Size Minimum purchase unit Weight (Kg) Box / carton
5025 02 45 V. 2025 1/4" WITH GN-05/S2 1 1.335 1/1
5025 03 45 V. 2025 3/8" WITH GN-05/S2 1 1.335 1/1
5025 04 73 V. 2025 1/2" WITH GN-15/S3 1 2.66 1/1
5025 05 74 V. 2025 3/4" WITH GN-15/S4 1 2.82 1/1
5025 06 49 V. 2025 1" WITH GN-17/S4 1 3.61 1/1
5025 07 76 V. 2025 1"1/4 WITH GN-20/S4 1 5 1/1
5025 08 77 V. 2025 1"1/2 WITH GN-25/S4 1 6.35 1/1
5025 09 78 V. 2025 2" WITH GN-30/S4 1 9.05 1/1
5025 10 79 V. 2025 2"1/2 WITH GN-35/S3 1 15.83 1/1
5025 11 80 V. 2025 3" WITH GN-40/S4 1 21.2 1/1
5025 12 81 V. 2025 4" WITH GN-45/S4 1 36.37 1/1
