2 pieces full bore ball valve - flanged ends

2 pieces full bore ball valve - flanges ends.
Body: ductil iron GGG-40. Ball and stem: AISI 304.
Seats: PTFE + 15% GF. Stem o’ring: viton.
Max. pressure: 16 kg/cm2. Temp. -30ºC +180ºC.
Manually operated by handle with locking system.
L: S/DIN 3202 F-4.
With GE multivoltage electric rotary actuator.
Required voltage must be specified.

Reference: 5625

Actuator single phase data sheet
Valve Technical Sheet
Consult product
Reference Size Minimum purchase unit Weight (Kg) Box / carton
5625 04 51 V. 2525 1/2" WITH GE-0 24/240V 1 4.15 1/1
5625 05 51 V. 2525 3/4" WITH GE-0 24/240V 1 4.8 1/1
5625 06 51 V. 2525 1" WITH GE-0 24/240V 1 5.5 1/1
5625 07 47 V. 2525 1"1/4 WITH GE-05 24/240V 1 0.001 1/1
5625 08 52 V. 2525 1"1/2 WITH GE-1 24/240V 1 10.65 1/1
5625 09 52 V. 2525 2" WITH GE-1 24/240V 1 11.9 1/1
5625 10 48 V. 2525 2"1/2 WITH GE-15 24/240V 1 17.26 1/1
5625 11 53 V. 2525 3" WITH GE-2 80/240V 1 25.45 1/1
5625 12 54 V. 2525 4" WITH GE-2 80/240V 1 29 1/1
