2 pieces full bore ball valve

2 pieces full bore ball valve.
Body: Stainless steel. CF8M (316) investment casting.
Seats: PTFE + 15% GF stem o’ring: viton. Antiestatic device.
Max. pressure: 40/16 BAR depending on size.
Temp.: -30ºC +180ºC. manually operated by handle.
L: DIN 3202 F-4 DN 15 DN 100 F-5 DN 125 DN 200.
With GNP actuator.

Reference: 5528

Valve Technical Sheet
GNP Actuator technical sheet
GNP Actuators folder
Consult product
Reference Size Minimum purchase unit Weight (Kg) Box / carton
5528 04 122 V. 2528 1/2" WITH GNP-14 1 3 1/1
5528 05 122 V. 2528 3/4" WITH GNP-14 1 3.85 1/1
5528 06 122 V. 2528 1" WITH GNP-14 1 4.55 1/1
5528 07 128 V. 2528 1"1/4 WITH GNP-44 1 7.85 1/1
5528 08 128 V. 2528 1"1/2 WITH GNP-44 1 9.1 1/1
5528 09 128 V. 2528 2" WITH GNP-44 1 11.6 1/1
5528 10 142 V. 2528 2"1/2 GNP-94 1 18.05 1/1
5528 11 142 V. 2528 3" WITH GNP-94 1 21.44 1/1
5528 12 150 V. 2528 4" WITH GNP-198 1 31.43 1/1
5528 14 162 V. 2528 6" WITH GNP-513 1 75.7 1/1
5528 16 166 V. 2528 8" WITH GNP-800 1 129.8 1/1
