Stainless steel butterfly valve wafer type

Body, stem and disc: stainless steel 316 (CF8M).
Stainless steel butterfly valve wafer type.
Seat: PTFE with EPDM backup ring. Temp. -25ºC +180ºC.
Manually operated by stainless steel handle until 5”, from 5” with gear operator. Face to face according to DIN 3202 K1. Working pressure: 10 bar
With GNP actuator.
-13ºF + 356ºF

Reference: 5114

View technical details
See other documents
Consult product
Reference Size Minimum purchase unit Weight (Kg) Box / carton
5114 09 144 V. 2104 2" WITH GNP-94/S5 1 0.01 1/1
5114 10 144 V. 2104 2"1/2 WITH GNP-94 1 0.01 1/1
5114 11 148 V. 2104 3" WITH GNP-135/S5 1 10.4 1/1
5114 12 156 V. 2104 4" WITH GNP-198/S6 1 13.2 1/1
5114 13 164 V. 2104 5" WITH GNP-513/S5 1 22.6 1/1
5114 14 168 V. 2104 6" WITH GNP-800/S5 1 32.9 1/1
5114 16 172 V. 2104 8" WITH GNP-1280/S5 1 60.8 1/1
