Wafer type butterfly valve
PN 10/16 ANSI 150 lbs

Body: cast iron + epoxy. Disk: zinc plated. Elastomer: EPDM. O’ring stem: NBR.
Max. temp. 120ºC. Flanges mounted actuators ISO 5211 handle up to 10” with gear operator from 12”.

Reference: 2103

Valve Technical Sheet
Installation Manual
Consult product
Reference Size Minimum purchase unit Weight (Kg) Box / carton
2103 09 BUTTERFLY V. WAFER TYPE 2" 1 2.693 1/7
2103 10 BUTTERFLY V. WAFER TYPE 2 1/2" 1 3.197 1/5
2103 11 BUTTERFLY V. WAFER TYPE 3" 1 3.65 1/5
2103 12 BUTTERFLY V. WAFER TYPE 4" 1 5.646 1/5
2103 13 BUTTERFLY V. WAFER TYPE 5" 1 7.207 1/3
2103 14 BUTTERFLY V. WAFER TYPE 6" 1 8.357 1/2
2103 16 BUTTERFLY V. WAFER TYPE 8" 1 13.74 1/1
2103 18 BUTTERFLY V. WAFER TYPE 10" 1 20.383 1/1
2103 20 BUTTERFLY V. WAFER TYPE 12" 1 37.175 1/1
2103 22 BUTTERFLY V. WAFER TYPE 14" 1 55.382 1/1
2103 24 BUTTERFLY V. WAFER TYPE 16" 1 74.927 1/1
2103 26 BUTTERFLY V. WAFER TYPE 18" 1 117.111 1/1
2103 28 BUTTERFLY V. WAFER TYPE 20" 1 140.183 1/1
